SR 3008

Prize Bridge Information

  • Year Awarded: 2005
  • Year Completed: 2003
  • Location: Raleigh, NC
  • Award Class: Short Span
  • Designer/EOR: TranSystems Corporation
  • Fabricator: Carolina Steel Corporation
  • Owner: North Carolina Department of Transportation
  • General Contractor: Blythe Construction, Inc.
  • Detailer: Carolina Steel Corporation

Structure Information

  • Structure Type: Plate Girder
  • Coating System: Weathering Steel
  • Span Length (ft): 102/16.5
  • Structure Length (ft): 125
  • Average Deck Width (ft): 82.3
  • Steel Weight/Deck Area (lb/ft²): 76.4
  • Amount of Steel (tons): 393
  • Cost: $3.6 million
